Volume of BBS003
BBS003 has a nominal volume of 1.62 m³ (99 × 99 × 165 cm, without spouts). We confirm the load capacity on request because the data sheet and specification differ. Until then only the full volume can be calculated: with dry sand (1.50 t/m³) that would be 2,425 kg, with plastic granules (0.60 t/m³) 970 kg. Plan filling and lifting equipment only with the confirmed load capacity.
Quantity planning with BBS003
How many BBS003 do you need for a given quantity of material? The table uses the nominal volume of 1.62 m³ and 180 pieces per pallet.
| Items | Material quantity | Bags at full volume | Pallets | Bags for sand at the load capacity limit | Pallets |
|---|---|---|---|---|---|
| BBS003 | 10 m³ | 7 | 1 | 7 | 1 |
| BBS003 | 25 m³ | 16 | 1 | 16 | 1 |
| BBS003 | 50 m³ | 31 | 1 | 31 | 1 |
| BBS003 | 100 m³ | 62 | 1 | 62 | 1 |
Handling of BBS003
- BBS003 has four lifting loops. With BBS003, always attach all four and close the outlet first.
- The inlet (swan neck) of BBS003 measures Ø 40 × 50 cm and is tied to the spout of the filling line. The outlet (Ø 40 × 50 cm) opens over the point of use.
- BBS003 is uncoated. Store it dry and covered; the fabric absorbs moisture.
- A pallet holds 180 pieces of BBS003. Store unused bags in their original packaging.
Open details for BBS003
For BBS003 the data sheet gives one value unclearly or not at all: the load capacity (SWL). It says “on request” there. We confirm the value in writing before your order. Plan lifting equipment, filling and number of pallets only with it, and ask via the enquiry form.
